Monport GQ 50W (7.9" x 7.9") Fiber Laser Engraver & Marking Machine with FDA Approval
Save $2,200.00
Current price
$3,299.99
$3,299.99
-
$3,589.98
Current price
$3,299.99
Original price
$5,499.99
Original price
$5,499.99
-
Original price
$5,499.99
Original price
$5,499.99
Free Shipping
US Delivery time : 3-5 Business Days
2-Year Warranty
Dimension
Working Area: 7.9" X 7.9"
Machine Dimension: 8.2" x 17.7" x 15.3"( 21cm x 45cm x 39cm )
Main Tower Dimension: 13.7" x 21.6" x 26,9" ( 35cm x 55cm x 68.5cm )
Field Lens Dimension: 200mm x 200mm
Fiber Lens Model: M85(85-68MM adapter)
Machine Weight: 73.8lbs ( 33.5 kg )
Monport 50W Features & Benefits
Galvo-tech Control
The Sino-Galvo delivers the laser beam with incredible speed and a much higher degree of accuracy than a regular CO2 laser. Its extreme stability ensures quick scanning, engraving, and project turnaround.
The Fiber Laser Source
The source has an estimated lifetime of up to 100,000 hours, depending on power setting usage, which can safely mark most metals, such as stainless steel, gold, silver, and brass.
Upgraded Button Design
Equipped with an emergency button for instant response. Our key switch bars unauthorized access, and the dual fans ensure continuous, stable operation.
Pre-assembled Fiber Laser
Monport split fiber machine arrives ready right out of the box, eliminating setup hassles. Dive straight into your metal engraving projects and bring your creative visions to life effortlessly.
Advanced Work Space
This laser machine has a built-in workspace grid with removable positioning bars for precise material placement. It also supports an optional rotary axis (not included) to mark tubes, bottles, pipes, and other curved surfaces.
Portable Size
The most versatile machine can accept a wide range of accessories sizes and fits well on a desk or can be taken in any studio easily.
Additional Laser Guidance
Once properly adjusted, the external red dot locator calibrates with the laser's scanner to allow a quick and accurate laser focus setup.
Manual Focus
By rotating the focus-height wheel, you can quickly focus the galvanometer laser on various materials like gold, silver, brass, stainless steel, etc . Plus, the vertical supporting tower is equipped with a ruler for convenient focus height measurements.
Monport 50W Specification
Compatibility
Includes EzCad or BslAppSimple software compatible with Windows XP/7/10 (32 and 64 bits)
Compatible with Lightburn, AutoCAD, CorelDraw and more supported image formats: BMP, GIF, JPG, DXF, PNG and others
Laser System
Rated at 50 watt
Maximum marking speed of 10000 mm/s
Laser Wavelength: 1064 nm
Material Capability
Metals: Stainless Steel, Aluminum, Common Alloys, anodized aluminum, Brass, Chromium, Gold&Silver, Titanium
Non-Metals: Slate, Hard Plastics, Artificial Leather, Colored Acrylic
Package Contents
50 Watt Fiber Laser Marker Machine *1
Power Cable *1
Foot Pedal *1
Laser Safety Glasses *1
USB Flash Drive *1
Clips *2
Bolts *4
Instruction Manual *1
Warranty & Certifications
- 2-year warranty on every fiber laser machine
- 1-year warranty on fiber laser source
- FDA Approved & CE Certified
About More
Download the User Manual: 50W Fiber User Manual
Download the Software: EzCad2
Download the Software Manual: EzCad2 Description
We offer compatible accessories: Fiber Laser Rotary
We sponsor CDR files: https://kokorosastudio.com
Questions & Answers
Have a Question?
-
I want to cut metal shapes, copper mainly. .06 to 2mm thick mostly. Is this possible?
Yes, this machine can cut .06 to 2mm thick copper, the Single Pass depth can reach to 0.1mm.
-
Will the 50 watt split monport GQ engrave Nambe Alloy pieces?
Yes, The GQ50W fiber laser can engrave on Nambe Alloy pieces. It can engrave on solder masks, plastics (hard and non-transparent), metals and wood. (No plexiglass) .
-
what size lens does GQ 50w come with?
The GQ 50W giber laser come with a 200mm lens
-
What is the highest object you can engraved?
There is no limit on the height of the object.
By rotating the vertical arm 90° and placing the lens outside the workbench, you can engrave objects of any height with the height difference. -
what is the frequency rating?
Thank you for your attention and your contact!
Its laser frequency is 50-100 KHZ. -
I would like to know more about this product.
To know more about this product, you may check it here: https://monportlaser.com/collections/fiber-laser-engravers/products/monport-50w-fiber-laser-engraver
-
: What are the update points for split fiber laser marking machines?
1.One-click start design
2. Safety key protection
3.Emergency Button
4.Advanced cooling fans -
: Which Fiber Laser Engraver should I choose?
: Spilted & GP Series: Standard marking/partial engraving on most metal materials, stone and hard plastic. GI Series: Faster marking/engraving on most metal materials, stone and hard plastic. + High-precision marking + Color marking on titanium and stainless steel (with high recovery and accuracy on metal materials)
-
: What brand of laser is used in the split fiber marking machine?
: The laser brand of GQ series is Max.
-
: What engraving software does this split fiber marking machine require? Which computer systems is the software compatible with?
: This machine comes with EZcad or BslAppSimple (Coexistence of new and old versions, with the new version being BslAppSimple and the old version being EZcad) engraving software, it can be compatible with Windows XP, WIN7, WIN8, Win10, Win11.If your computer system is a mac, you can purchase the GALVO version of Lightburn software to connect to the machine.
-
: Besides the rotary, what other accessories do you provide?
: At present we only provide the lens and rotary. But we are also planning to release the cover and the air purifier. So if you have that need, please contact us.
See How GQ Fiber Laser Marks on Rotary Cups
FEATURES
Monport 50w Features
Fiber Laser Source
Fiber laser source estimated lifetime of up to 100,000 hours.
100,000 hours
Galvo-tech
Precise Focus
By rotating the focus-height wheel, you can quickly focus the item.
Red Dot Guidance
ManualFocus
Variety Materials Capability
Monport fiber can engrave most metals and non-metals such as Slate, Hard Plastics, Artificial Leather, Colored Acrylic.
Speed: 10000mm/s
Various Materials
Curving Engraving
With rotary axis, the fiber laser can easily curving engrave.
under 30 minutes
Accuracy: 0.01mm
DETAILED PARAMETERS
Compare Each Fiber Laser Model
| Product | GQ 20 | GQ 30 | GQ 50 | |
| Input Power | 110-120V 60Hz | |||
| Rated Power | 20W | 30W | 50W | |
| Expected Service Life | 100,000 hr. | |||
| Central Wavelength | 1064 nm | |||
| Laser Frequency | 30-60 kHz | 40-60 kHz | 50-100 kHz | |
| Beam Diameter | 5.7-8 mm | 5.7-8 mm | 5.7-8 mm | |
| Beam Quality M2 | ＜1.5 | ＜1.6 | ＜1.6 | |
| Maximum Pulse Energy | 0.67 | 0.75 | 1 | |
| Processing Area | 4.3x4.3 in. (110×110 mm) |
5.9x5.9 in. (150×150 mm) |
7.9x7.9 in. (200×200 mm) |
|
| Max. Marking Speed | 393.7 ips(10000 mm/s) | |||
| Min. Marking Depth | 0.0002 in.(0.005 mm) | |||
| Max. Marking Depth on a Single Pass |
0.002in. (0.04mm) |
0.003in. (0.08mm) |
0.004in. (0.1mm) |
|
| Min. Line Width | 0.006 in.(0.15 mm) | |||
| Precision | ±0.1 µm | |||
| Required Operating Environment |
Max. Humidity | <70% | ||
| Temp. Range | 32–104°F(0 - 40°C) | |||
| Provided Operating Software | EZCad or BslAppSimple（Coexistence of new and old versions, with the new version being BslAppSimple and the old version being EZcad） | |||
