Laser Power: 60W

Working Area: 6.9"x 6.9"
Wavelength: 1064nm
Machine Dimension: 42cm x 35cm x 62cm

Package Dimension: 74cm x 61cm x 36cm

Marking Speed: 10000mm/s （Up to 15000mm/s）
Expected Service Life (MTTF): 100,000 hr.

All-in-One Fiber LaserExperience Monport's latest, independently developed autofocuslaser marking machine. Upgraded for enhanced performance and cost-effectiveness, users can enjoy advanced features without significant cost increase. The machine arrives ready-to-use with easy installation, quick setup, and user-friendly operation.
Aluminum Body with Integrated OpticsMonport combines functionality and aesthetics in industrial gradefiber laser engravers. The entire machine features a robust aluminum casing, with the auto-focus and galvanometer modules integrated into the optical path. This integration, paired with sleek exterior lines and a minimalist structure, positions it far ahead of industry competitors.
Auto-Focus InnovationMonport introduces our proprietary auto-focus technology, achieving high precision with a single click (error＜±1mm). This streamlined process enhances work efficiency and focus accuracy compared to traditional manual methods. For added flexibility, manual focus is also possible, supported by three red lights.
Enhanced PerformanceBeyond its outstanding design, Monport's desktop marking machine outperforms competitors also in performance. Every component has been rigorously tested for ultra-high stability, precision positioning, rapid marking speeds, and robust anti-interference capabilities (see detailed specifications for reference).
±90° Vertical Arm RotationThe vertical arm offers an infinitely adjustable range of ±90°. Users can fix it at any angle within this range, promoting unlimited creativity in marking applications. Adjustments are convenient, requiring just the loosening of screws without the need for complete unscrewing.
Widely adjustable frequency and pulse widthStainless steel colorful marking，including anodized aluminum black marking, precision cutting, drilling, conventional marking, plastic keystroke surface marking, etc.
（Note: Laser Frequency 1-3000kHz，Pulse Width 2-500ns）
One-Minute InstallationInstalling this LightBurn compatible fiber laser marker is a breeze with its excellent foldable vertical arm design —just tighten two screws, and you're ready to go. Monport promises that even beginners can complete the setup within a minute after unboxing for a hassle-free experience.

Fiber marking machine*1

Marking test cards*8

USB data cable*1

U disk*1

Wrench*1

Steel ruler*1

Positioning bar*2

Screw*4

Power line*1

Protective glasses*1

Instruction*1

• 2-year parts warranty on all GA MOPA fiber laser machines
• 1-year warranty on fiber laser source

Some tips about delivery in the continental US (except preorder)

You will get the tracking number within 2 business days.

The delivery time varies from 3 to 7 business days.

If your address is outside the continental US, Please read the Shipping Policy carefully before buying.

If the arrived outer package is damaged, please refuse to sign for it and take a photo, then contact Monport via support@monportlaser.com.

We are very glad to help you with the exchange process.

Download GA User Manual Here
